Continious Motion Packaging Machines

Efficient, High-Speed Packaging Solutions

At VDL Packaging, we understand the importance of efficiency and speed in your packaging operations. Our Continuous Motion Baggers are designed to meet the demands of high-volume production lines, ensuring seamless and uninterrupted packaging processes.

What is a Continuous Motion Bagger?

A Continuous Motion Bagger is a type of vertical form-fill-seal (VFFS) machine that operates without stopping between packaging cycles. This continuous operation allows for higher production speeds and greater efficiency compared to intermittent motion baggers. Here's how it works:

Forming the Bag: The machine unwinds a roll of flat plastic film, which is guided by a forming tube to shape the film into a pouch of the desired size.
Filling the Bag: Once the pouch is formed, it is held open by a clamp. The product is then dispensed into the open pouch using various filling mechanisms, such as weight, auger, pump, or volumetric cup, depending on the product's characteristics.
Sealing the Bag: After filling, the pouch is heat-sealed closed at the top. Some machines can also create a seal at the bottom of the pouch, depending on the desired style (e.g., pillow pouch vs. doy pouch).
Trimming and Completing the Package: After sealing, the pouch is cut from the remaining film. The finished package can then have additional features added, such as a date code, a tear notch for easy opening, or a hole punch for hanging.

Key Features of Our Continuous Motion Baggers:

High-Speed Operation: Capable of producing up to 150 bags per minute, making them ideal for high-volume production lines.
Versatility: Handles multiple package formats and produces a wide range of package sizes, providing flexibility for both retail and club-size packaging.
Hygienic Design: Built with stainless steel and anodized aluminum construction, our baggers are easy to clean and maintain, meeting the highest sanitary standards.
User-Friendly Interface: Equipped with an intuitive HMI (Human-Machine Interface) for easy operation and quick changeovers between different packaging formats.

Applications:

Our Continuous Motion Baggers are suitable for a wide range of industries, including food and beverage, personal care, pharmaceuticals, and more. Whether you need to package snacks, powders, liquids, or other products, our machines deliver reliable performance and exceptional quality.
